ISOKING™ Fiberglass Insulation for Pipes

White Faced Glass Wool Pipe Product Introduction

1. Product Overview: Core Positioning of White Faced Glass Wool Pipes

The white faced glass wool pipes produced by our factory are tubular thermal insulation products made from core raw materials such as quartz sand, feldspar, and soda ash, which are melted at high temperature, centrifuged into fibers, solidified with formaldehyde-free thermosetting binders, and compounded with special white facing on the outer layer. The product is mainly suitable for B-end scenarios such as industrial pipelines and HVAC systems, with multiple characteristics including thermal insulation, moisture resistance, fire resistance, and noise reduction. It can be directly applied to various pipeline insulation projects without the need for additional moisture-proof layers, greatly improving construction efficiency.

2. Core Applications: Adapting to Pipeline Insulation Needs in Multiple Fields

Industrial Pipeline Insulation Field

Widely used in medium and low temperature pipeline insulation in industries such as petrochemical, power energy, metallurgy and mining, covering industrial steam pipelines, chilled water pipelines, process medium transmission pipelines, etc. It can effectively reduce the cold and heat loss of the medium in the pipeline, lower energy consumption, protect the pipeline from external environmental corrosion, avoid pipeline damage caused by temperature changes, and ensure the stable operation of industrial production. For high-temperature working conditions, it can be used with high-temperature resistant glass wool products, adapting to a wide temperature range of -120℃ to 350℃.

HVAC System Insulation

Suitable for the insulation of central air conditioning cold and hot water pipelines, heating pipelines and ventilation pipelines in large-scale buildings such as commercial complexes, office buildings, hospitals, and factories. The white facing has excellent moisture-proof and vapor barrier performance, which can effectively prevent pipeline condensation and mold, avoid condensation water damage to walls and surrounding equipment, reduce energy consumption loss of the air conditioning system, help buildings achieve energy-saving goals.

Specialized Applications in Special Scenarios

According to the customized needs of customers, it can adapt to the pipeline insulation and noise reduction needs of special scenarios such as shipbuilding, rail transit, and medical facilities, such as ship pipeline insulation, subway vehicle pipeline insulation, hospital operating room pipeline insulation, etc. It balances thermal insulation performance and environmental adaptability, meeting the special standard requirements of different industries. At the same time, it can adapt to different environments such as indoor dry concealed projects and outdoor pipelines, flexibly matching various construction scenarios.

3. Product Advantages

Efficient Thermal Insulation and Significant Energy Saving Effect

The internal fibers of the product are arranged in a disorderly and interlaced manner, forming a large number of tiny air pockets. The thermal conductivity can be stably controlled between 0.032W/(m·K) and 0.042W/(m·K), and the thermal insulation performance is better than the industry average. It can effectively reduce the cold and heat loss of the pipeline, help enterprises reduce energy operation costs in the long run, meet the needs of industrial energy conservation and building energy conservation, and comply with the latest building energy conservation regulations. The average fiber diameter is controlled below 6 microns, further improving the thermal insulation stability.

Integrated White Facing Design for Better Moisture Protection

The outer white facing is made of high-strength glass fiber cloth or special moisture-proof facing material, which is closely bonded to the glass wool pipe body through a special compound process. There is no need for additional winding of moisture-proof layers, making construction convenient and efficient. At the same time, it has excellent moisture resistance, radiation resistance, and tear resistance, which can effectively block the invasion of external water vapor, avoid moisture aging of the insulation layer, extend the service life of the product, reduce later maintenance costs, and adapt to different climate environments

Safety, Environmental Protection and Strong Compliance

The product is made of formaldehyde-free thermosetting binder, with no release of toxic and harmful gases and no peculiar smell. It meets the green building material standards and indoor environmental protection requirements, and can be directly applied to densely populated buildings and industries with high environmental protection requirements such as food and medical care. At the same time, it is a Class A non-combustible material, certified by GB 8624-2012 "Classification of Combustion Performance of Building Materials and Products". It does not burn when exposed to fire and does not produce toxic flue gas, which can effectively improve the fire safety level of the pipeline insulation system and avoid potential safety hazards in industrial and construction fields.

Convenient Construction and Strong Adaptability

The product adopts a half-split structure design, with soft texture and light bulk density. It can be flexibly cut according to the pipeline diameter, adapting to conventional pipe diameters from DN15 to DN800, and supporting customization of large pipe diameters (350-2000mm). The inner diameter tolerance of the pipe shell is strictly controlled, facilitating on-site joint installation, greatly improving construction efficiency and reducing construction loss (the loss rate can be controlled within 3%). It can be used with supporting tapes, iron wires or metal casings, with joints laid staggeredly, and multi-layer insulation adopts a pressure joint method, adapting to the insulation needs of special-shaped parts such as pipe fittings, valves and flanges.

Outstanding Cost-Effectiveness and Greater Advantages in Bulk Purchases

Bulk purchases can enjoy exclusive factory prices, greatly reducing customers' procurement costs. At the same time, the product has stable performance and a service life of more than 15 years, without frequent replacement, balancing cost-effectiveness and practicality. Compared with polyurethane pipe shells, it has a wider applicable temperature range and better fire resistance; compared with rock wool pipes, it has lower thermal conductivity and softer texture, adapting to more scenario needs.

4. Factory Advantages: Source Strength to Ensure Worry-Free Cooperation

Large-Scale Production, Sufficient Capacity and Timely Delivery

Our factory is a professional glass wool production enterprise, equipped with multiple automated production lines, with an annual output of more than 100,000 tons, of which the annual output of white faced glass wool pipes can reach 80,000 cubic meters. It can meet the large-volume and multi-specification procurement needs of B-end customers. Whether it is conventional specifications or customized products, it can ensure on-time delivery, avoiding delays in project progress due to delayed delivery.

Mature Core Technology and Strict Quality Control

We have a professional R&D and production team, deeply engaged in the glass wool field for many years, mastering core production processes such as centrifugal fiber forming and facing compounding. We have introduced advanced production equipment and a constant temperature and humidity laboratory. Each batch of products undergoes random inspections of indicators such as thermal conductivity, fire resistance, and moisture resistance, realizing full-process digital quality control. The product performance stability rate is over 99%, ensuring that each batch of products meets industry standards and customer needs. Authoritative test reports and qualification certificates can be provided to assist customers in project acceptance.

Strong Customization Capability to Adapt to Diverse Needs

We can customize white faced glass wool pipes with different pipe diameters, different thicknesses (20mm-100mm), different densities (24kg/m³-120kg/m³) and different facing materials. At the same time, we can provide value-added services such as thermal insulation thickness calculation and on-site construction technical guidance. We launch specially adapted products for special working conditions (high temperature, high humidity, strong vibration) to meet the personalized needs of different fields such as industry and construction.

Complete Qualifications and Improved After-Sales System

The factory has complete production qualifications, environmental protection qualifications and product testing qualifications. All products have passed authoritative certifications such as Class A non-combustible certification and green building material certification. Complete qualification documents can be provided to ensure the compliance of customers' procurement and help customers successfully pass project acceptance.

Direct Supply from Source Factory and Flexible Cooperation Model

We support bulk purchases and long-term strategic cooperation with B-end customers, and can provide OEM/ODM OEM services to adapt to the cooperation needs of different customers such as distributors and engineering companies. We provide reasonable procurement quotes and preferential policies, and also provide sample delivery services to allow customers to test product quality in advance. We provide one-on-one follow-up throughout the process to simplify the procurement process and reduce procurement costs.

5. Contact Us

For more information or cooperation inquiries, please reach out to our professional team, and we will provide you with attentive and efficient services.
